Electrical parameters:
1.Frequency range: 1710-2170MHz 2200-2500MHz 2500-2690MHz
2.Polarization: ±45°
3.Gain: 14.5dbi
4.Down-tilt:0°
5.Horizontal beam width: 32°±5
6.Vertical beam width: 33/28/24
7.Cross polarization ratio: axis direction≥20, ±15°≥15
8.Front-to-back ratio:>28dB
9.VSWR: ≤1.5
10.Isolation degree:>28dB
11.Third order intermodulation: <-107dBm
12.Input impedance: 50Ω
13.Power capacity: 350W
14.Anti-lightning protection: DC ground
Mechanical performance illustration:
1.Product category:2×N female
2.Size (without packet):295*280*80mm
3.Size (with packet):320*300*120mm
4.Weight (without packet):3.1kg
5.Weight (with packet):3.4kg
6.Wind load area：0.427m2
7.Wind resistance: 60m/s
8.Antenna shield material: UPVC
9.Interface position: bottom
10.Mechanical down-tilt: 0~15°
11.Operating temperature: -50~+60℃
12.Pole mounted: ￠50~￠115
13.Limited temperature: -55~+75
14.Operating humidity: 8%~98%
Product feature:
This antenna is widely used with advantages including easy site construction, easy maintenance, low cost and high gain.
