Electrical parameters:
1.Frequency range: 2400-2500MHz 5150-5850MHz
2.Polarization: 2*vertical
3.Gain:10±0.5dbi(2400-2500MHz) 12±0.5dbi(5150-5850MHz)
4.Beam width: Horizontal 65±5°, vertical 65±3°
5.Front-to-back ratio: ≥23dB
6.VSWR: ≤2.0
7.Isolation degree: ≥22dB
8.Input impedance: 50Ω
9.Power capacity: 100W
10.Anti-lightning protection: DC ground
Basic mechanical performance:
1. Product category: N-J
2.Size (without packet):220*220*30mm
3.Weight (without packet):1.2kg
4.Antenna shield material: ABS
5.Reflection board material: Aluminum / copper
6.Antenna shield color: white
7.Operating temperature: -30~+50℃
8.Operating humidity: <95%
9.Wind resistance: 36.9m/s
10.Pole mounted: ￠40~￠55
Product feature:
Wider frequency band, better connectivity, symmetrical main lobe, strong anti-interference ability, convenient site construction and easy maintenance.
